ICON Stage 4 Suspension System for 1995.5-2004 Toyota Tacoma

Name: ICON Stage 4 Suspension System for 1995.5-2004 Toyota Tacoma
Brand: ICON
SKU: K53014
Price: 3610.35 USD
Availability: InStock

$3,610.35 USD

Sale Sold out

Shipping calculated at checkout.

SKU:K53014

In stock

Calculated shipping — oversized item
Ships in 1–2 business days
30-day hassle-free returns
Price match — found it cheaper?
Secure checkout — SSL encrypted

Key Features

Up to 3in of adjustable front lift for larger wheel and tire fitments
2.5in extended-travel front coilovers with remote reservoirs and ICON-tuned coil springs
Patented Delta Joint tubular upper control arms for durability and corrected geometry
Extended-travel design maximizes off-road wheel travel and articulation
Rear 2.0 Series reservoir shocks with add-a-leaf for balanced front-to-rear stance
Vehicle-specific tuning delivers a refined on-road ride and capable off-road performance
Complete front-and-rear bolt-on package for the 1st-gen Tacoma

Transform your 1995.5-2004 Toyota Tacoma with the ICON Vehicle Dynamics Stage 4 Suspension System, a complete front-and-rear package that pairs extended-travel coilovers and tubular upper control arms with rear reservoir shocks for true off-road capability and a refined on-road ride.

Key Benefits

Up to 3in of adjustable front lift to clear larger, more aggressive wheel and tire combinations
2.5in extended-travel front coilovers with remote reservoirs and ICON-tuned coil springs for fade-resistant control
Patented Delta Joint tubular upper control arms restore proper geometry and add durability over factory ball joints
Extended-travel design unlocks more wheel travel for improved articulation off-road
Rear 2.0 Series reservoir shocks plus an add-a-leaf kit balance the lift front to rear
Engineered, vehicle-specific tuning for a comfortable street ride that still performs under load

What's Included

Pair of 2.5in extended-travel front coilovers with remote reservoirs and coil springs
Pair of tubular upper control arms with Delta Joint technology
Pair of rear 2.0 Aluminum Series remote-reservoir shocks
Rear add-a-leaf kit (approximately 1.5in rear lift)
Required mounting hardware

Fitment

Engineered specifically for the 1995.5-2004 Toyota Tacoma 4WD and PreRunner (6-lug). Not compatible with 5-lug 2WD models. This Stage 4 system requires the included aftermarket tubular upper control arms; professional installation and a four-wheel alignment are recommended.

1995.5-2004 Toyota Tacoma (4WD / PreRunner) - Front

FAQ

Does this ICON Stage 4 system fit a 2WD Tacoma?

No. It fits the 1995.5-2004 Toyota Tacoma in 4WD and 6-lug PreRunner form only and will not fit 2WD Tacoma with 5-lug wheel studs. It does not fit the 2005 and newer second-generation Tacoma.

How much lift does the ICON K53014 provide?

The front coilovers are height-adjustable up to 3.5 inches with about 1.5 inches of rear lift from the add-a-leaf. Larger tires are supported up to 33x11.50, and fender trimming may be required beyond that.

What is the difference between this Stage 4 system and the other ICON Tacoma stages?

Stage 4 adds tubular Delta Joint upper control arms and extended-travel front coilovers over Stage 3. This complete system includes ICON tubular Delta Joint upper control arms.

Vehicle Fitment

Years	Make	Model	Submodel	Position
1995–2004	Toyota	Tacoma	—	Front

Specifications

valve: CDCV
rear lift: ~1.5 in (add-a-leaf)
drivetrain: 4WD / PreRunner (6-lug); not 2WD 5-lug
front lift: 0-3 in adjustable (up to 3.5 in)
rear shock: 2.0 in Aluminum Series, 5/8 in shaft, remote reservoir
valve type: V.S. velocity-sensitive (non-adjustable damping)
front shock: 2.5 in coilover, 7/8 in shaft, remote reservoir, extended travel
rear shocks: 2.0in Aluminum Series, 5/8in shaft, remote reservoir
front shocks: 2.5in coilover, 7/8in shaft, remote reservoir, extended travel
upper control arms: tubular with patented Delta Joint
