ICON Stage 1 Suspension System for 05-23 Toyota Tacoma

Name: ICON Stage 1 Suspension System for 05-23 Toyota Tacoma
Brand: ICON
SKU: K53001
Price: 1909.65 USD
Availability: InStock

$1,909.65 USD

Sale Sold out

Shipping calculated at checkout.

SKU:K53001

In stock

Calculated shipping — oversized item
Ships in 1–2 business days
30-day hassle-free returns
Price match — found it cheaper?
Secure checkout — SSL encrypted

Key Features

Height-adjustable 2.5-inch front coilovers with ICON-engineered springs
2.0 Aluminum Series rear shocks tuned to match
0-3.5 in front lift (05-15), 0-2.75 in (16-23); TRD Pro 0-1.25 in
4WD only; will not fit 2WD 5-lug Tacoma
Expandable Stage system; add UCAs and Add-A-Leaf later
Fits 2005-2023 Toyota Tacoma

The ICON Vehicle Dynamics K53001 is a Stage 1 suspension system for the 2005-2023 Toyota Tacoma (4WD), pairing height-adjustable 2.5 Series front coilovers with 2.0 Aluminum Series rear shocks.

Key Benefits

Height-adjustable 2.5-inch front coilovers with internal reservoir and ICON-engineered springs
2.0 Aluminum Series rear shocks tuned to match the front for a balanced ride
0-3.5 inches of front lift on 2005-2015 models, 0-2.75 inches on 2016-2023 models
Entry point into ICON's Tacoma Stage system, expandable with UCAs and a rear Add-A-Leaf
Bolt-on install with no cutting or welding

What's Included

Pair of ICON 2.5 Series front coilovers with internal reservoir and ICON-engineered springs
Pair of ICON 2.0 Aluminum Series rear shocks

Specifications

Brand: ICON Vehicle Dynamics
System: Stage 1 (front coilovers + rear shocks)
Front: 2.5 Series internal-reservoir coilovers, height-adjustable
Rear: 2.0 Aluminum Series shocks
Front lift: 0-3.5 in (2005-2015), 0-2.75 in (2016-2023); TRD Pro 0-1.25 in
Drivetrain: 4WD only

Fitment

Fits the 2005-2015 and 2016-2023 Toyota Tacoma in 4WD. Front lift is 0-3.5 inches on 2005-2015 models and 0-2.75 inches on 2016-2023 models; 2017-2023 TRD Pro models are limited to 0-1.25 inches of front lift. Does not fit 2WD Tacoma models with 5-lug wheel studs. Stage 1 does not include upper control arms or a rear Add-A-Leaf; step up to Stage 2 (K53002) for the Add-A-Leaf or Stage 3/4 for billet or tubular UCAs.

FAQ

What comes in the Stage 1 system?

It includes a pair of height-adjustable 2.5 Series front coilovers with ICON-engineered springs and a pair of 2.0 Aluminum Series rear shocks. It does not include upper control arms or an Add-A-Leaf.

How much lift does Stage 1 provide?

Front lift is 0-3.5 inches on 2005-2015 Tacomas and 0-2.75 inches on 2016-2023 Tacomas; TRD Pro models are limited to 0-1.25 inches.

Does it fit a 2WD Tacoma?

No. The K53001 fits 4WD models only and will not fit 2WD Tacomas with 5-lug wheel studs.

How is Stage 1 different from Stage 2?

Stage 2 (K53002) adds a rear Add-A-Leaf kit for 1.5 inches of rear lift; Stage 1 is front coilovers and rear shocks only.
