ICON Delta Joint Retrofit Kit for 2005-2023 Toyota Tacoma/Tundra

Name: ICON Delta Joint Retrofit Kit for 2005-2023 Toyota Tacoma/Tundra
Brand: ICON
SKU: 614560
Price: 332.72 USD
Availability: InStock

$332.72 USD

Sale Sold out

Shipping calculated at checkout.

SKU:614560

In stock

Calculated shipping — oversized item
Ships in 1–2 business days
30-day hassle-free returns
Price match — found it cheaper?
Secure checkout — SSL encrypted

Key Features

Retrofits ICON's sealed Delta Joint into non-ICON aftermarket upper control arms
Ball-joint durability with high-angle uniball performance
Replaces 1-inch uniballs (2.125 in OD) such as WSSX16, AWX16, WC16, WE16
Sold as a pair with retaining rings and anti-seize
Does not fit ICON arms; not a complete control arm
Fits 2005-2023 Tacoma and 2007-2021 Tundra aftermarket UCAs

The ICON Vehicle Dynamics 614560 is a Delta Joint retrofit kit that installs a pair of ICON's patented Delta Joints into non-ICON aftermarket upper control arms using 1-inch uniballs, for the 2005-2023 Toyota Tacoma and 2007-2021 Toyota Tundra.

Key Benefits

Converts an existing aftermarket upper control arm from a uniball to ICON's sealed Delta Joint
Combines the durability of a ball joint with the high-angle performance of a uniball
Sealed design resists dirt, water, and wear better than an open uniball
Sold as a pair to upgrade both driver and passenger upper control arms
Includes retaining rings and anti-seize for installation

What's Included

Pair of ICON Delta Joints
Retaining rings
Anti-seize compound

Specifications

Brand: ICON Vehicle Dynamics
Type: Delta Joint retrofit kit (pair)
Replaces: 1-inch uniballs with a 2.125 in outside diameter and 1 in height (WSSX16, AWX16, WC16, WE16, WSSB16, WR16, ABW16)
Fits into: Non-ICON aftermarket upper control arms only
Position: Front upper control arms (pair)

Fitment

Fits non-ICON aftermarket upper control arms on the 2005-2023 Toyota Tacoma and 2007-2021 Toyota Tundra that use a 1-inch uniball (2.125 in OD, 1 in height). It replaces the uniball in an arm you already own. Does not fit ICON upper control arms, which already use the Delta Joint. It is not a complete upper control arm and does not add lift on its own. For the 4Runner, FJ Cruiser, GX, and 200 Series Land Cruiser, use the 614561 instead.

FAQ

What does the 614560 do?

It retrofits ICON's sealed Delta Joint into a non-ICON aftermarket upper control arm that currently uses a 1-inch uniball.

Is this a complete upper control arm?

No. It is the joint only, sold as a pair, and installs into upper control arms you already own. It does not fit ICON arms, which already have the Delta Joint.

Which uniballs does it replace?

It replaces 1-inch uniballs with a 2.125-inch outside diameter and 1-inch height, including WSSX16, AWX16, WC16, WE16, WSSB16, WR16, and ABW16.

Which vehicles does it cover?

It covers the 2005-2023 Toyota Tacoma and 2007-2021 Toyota Tundra; use the 614561 for the 4Runner, FJ Cruiser, GX, and 200 Series Land Cruiser.
