ICON 2.5 VS IR Front Coilover Kit for 2005-2023 Toyota Tacoma

Name: ICON 2.5 VS IR Front Coilover Kit for 2005-2023 Toyota Tacoma
Brand: ICON
SKU: 58631-CB
Price: 1677.45 USD
Availability: InStock

$1,677.45 USD

Sale Sold out

Shipping calculated at checkout.

SKU:58631-CB

In stock

Calculated shipping — oversized item
Ships in 1–2 business days
30-day hassle-free returns
Price match — found it cheaper?
Secure checkout — SSL encrypted

Key Features

matched to the Pro Comp 6-inch lift of ICON-tuned adjustable front lift via the threaded lower spring seat
2.5-inch shock body with increased piston area for better heat management and fade resistance
Internal-reservoir (IR) design adds oil capacity without external plumbing
Vehicle Specific (V.S.) length and damping tune configured for this exact platform — non-adjustable (no CDCV knob or CDEV electronic controller)
CNC-machined 6061 aluminum components, CAD-plated shock body and 7/8-inch shaft
Fully rebuildable and revalvable for long service life

The ICON Vehicle Dynamics 58631-CB is a Vehicle Specific (V.S.) 2.5 Series front coilover kit for the 2005-2023 Toyota Tacoma.

It replaces the tired factory front struts with a rebuildable 2.5-inch internal-reservoir coilover tuned specifically for this platform.

Key Features

matched to the Pro Comp 6-inch lift of ICON-tuned adjustable front lift via the threaded lower spring seat
2.5-inch shock body with increased piston area for better heat management and fade resistance
Internal-reservoir (IR) design adds oil capacity without external plumbing
Vehicle Specific (V.S.) length and damping tune configured for this exact platform — non-adjustable (no CDCV knob or CDEV electronic controller)
CNC-machined 6061 aluminum components, CAD-plated shock body and 7/8-inch shaft
Fully rebuildable and revalvable for long service life
Shocks are fully rebuildable and revalvable; ICON coil springs are guaranteed for life against sagging or breakage (shock bodies carry ICON's 12-month manufacturer-defect warranty).

What's Included

Pair of assembled front coilovers (left and right) with pre-installed ICON coil springs
Mounting hardware
Front kit only — rear shocks are sold separately

Fitment

Fits the following applications, verified for ICON part number 58631-CB: 2005-2023 Toyota Tacoma. This is the length- and valve-matched coilover for a Pro Comp 6-inch suspension lift; it is not a standalone lift kit. Does not fit 2WD 5-lug Tacoma models. Engineered for a Toyota Tacoma already fitted with a Pro Comp 6-inch suspension lift (sold separately) — it is not a standalone lift kit. Front kit only where applicable; rear shocks and any required control arms are sold separately.

2005-2023 Toyota Tacoma

FAQ

What is 58631-CB for?

It is a Vehicle Specific coilover length- and valve-matched to a Pro Comp 6-inch suspension lift on the 2005-2023 Tacoma. The Pro Comp lift is sold separately.

Is this a complete lift kit?

No. It replaces the basic struts in a Pro Comp 6-inch lift with ICON damping; it does not by itself lift the truck.

Are these electronically adjustable?

No. They use ICON's non-adjustable Vehicle Specific (V.S.) valving with a height-adjustable spring seat.

Vehicle Fitment

Years	Make	Model	Submodel	Position
2005–2023	Toyota	Tacoma	—	Front

Specifications

notes: Designed for a Toyota Tacoma running a Pro Comp 6-inch suspension lift
valve: fixed (non-adjustable; not CDCV/CDEV)
series: 2.5 VS (Vehicle Specific)
damping: gas-charged oil
sold as: front pair
valving: Vehicle Specific, non-adjustable (no CDCV or CDEV)
reservoir: Internal reservoir (IR)
adjustment: height-adjustable spring seat
shock body: 2.5-inch diameter, CNC-machined 6061 aluminum, CAD-plated, 7/8-inch shaft
standalone lift: no
body diameter: 2.5 in
front lift range: matched to the Pro Comp 6-inch lift
designed for lift: Pro Comp 6 in (sold separately)
mounting position: Front (sold as a pair)
