Cognito 3in SM Standard Leveling Kit 20-25 Silverado/Sierra

Name: Cognito 3in SM Standard Leveling Kit 20-25 Silverado/Sierra
Brand: Cognito
SKU: 110-P1236
Price: 899.95 USD
Availability: InStock

$899.95 USD

Sale Sold out

Shipping calculated at checkout.

Free Shipping

SKU:110-P1236

In stock

FREE shipping on this item
Ships in 1–2 business days
30-day hassle-free returns
Price match — found it cheaper?
Secure checkout — SSL encrypted

Key Features

3-inch front leveling kit for 2020-2025 Silverado/Sierra 2500HD/3500HD
Includes SM Series boxed upper control arms with ball joints and pivot bushings
Forged torsion-bar adjuster keys plus front shock spacers
Levels the nose-down rake and clears up to a 35x12.50 tire
Bolt-in install, approx 3 hours; fits 2WD and 4WD
Powder-coated, made-in-USA components

The Cognito 110-P1236 3-inch SM Series Standard Leveling Kit raises the front of the Chevrolet Silverado and GMC Sierra 2500HD/3500HD by 3 inches to level the factory nose-down rake and clear larger tires. It combines Cognito's boxed SM Series upper control arms with forged torsion-bar keys and front shock spacers for a bolt-in lift that keeps front-end geometry in check.

Fitment

Fits 2020-2025 Chevrolet Silverado 2500HD/3500HD and GMC Sierra 2500HD/3500HD, both 2WD and 4WD. This is a front leveling kit.

Does not fit the 1500 (light-duty) trucks or pre-2020 HD trucks - it is specific to the 2020-up (T1XX) HD torsion-bar front suspension.

What's Included

The kit is a complete front leveling package: a Cognito SM Series (boxed sheet-metal) upper control arm kit with ball joints and maintenance-free pivot bushings, a torsion-bar adjuster key kit, and front shock spacers/extensions. No rear components are included; this levels the front to the rear.

Specs

Front lift: 3 inches
Kit type: leveling kit (front) - not sold each/pair
Includes: SM Series upper control arms (ball joints + pivot bushings), torsion-bar keys, front shock spacers
Max tire: up to 35x12.50 on a 9-in wheel with 5-in backspacing
Control arms: forged/boxed, semi-gloss black powder coat; made in USA
Install: bolt-in, approx 3-hour DIY

FAQ

What does the Cognito 110-P1236 kit include?

SM Series upper control arms (with ball joints and maintenance-free pivot bushings), a torsion-bar adjuster key kit, and front shock spacers - everything to net 3 inches of front lift.

Will it fit a 1500 Silverado?

No. 110-P1236 is for the 2500HD/3500HD only, 2020-2025, and uses the HD torsion-bar front suspension.

Vehicle Fitment

Years	Make	Model	Submodel
2020–2025	Chevrolet	Silverado 2500HD	2WD/4WD
2020–2025	Chevrolet	Silverado 3500HD	2WD/4WD
2020–2025	GMC	Sierra 2500HD	2WD/4WD
2020–2025	GMC	Sierra 3500HD	2WD/4WD
