AMP Research

AMP PowerStep Plug N Play for 2019-2024 Ram 1500 All Cabs

Name: AMP PowerStep Plug N Play for 2019-2024 Ram 1500 All Cabs
Brand: AMP Research
SKU: 76240-01A
Price: 1849.99 USD
Availability: InStock

$1,849.99 USD

Sale Sold out

Shipping calculated at checkout.

SKU:76240-01A

In stock

Calculated shipping — oversized item
Ships in 1–2 business days
30-day hassle-free returns
Price match — found it cheaper?
Secure checkout — SSL encrypted

Key Features

Auto-deploys when a door opens and retracts flush under the rocker when the doors close
Plug-N-Play harness plugs into the factory OBD-II connector - no wire cutting or splicing
Extruded aluminum step, 6 in. wide with non-slip tread, rated to support 600 lb per side
Die-cast aluminum PTFE-coated linkage with stainless steel pivot pins
Weather-sealed electric motors and integrated LED step lights
Complete two-side kit with vehicle-specific brackets, harness, and hardware
Backed by AMP Research's 5-year/60,000-mile limited warranty

The AMP Research PowerStep Plug-N-Play (76240-01A) is a complete pair of electric retractable running boards for the 2019-2024 Ram 1500 (new DT body) in all cab configurations. Each board deploys the instant a door opens and retracts flush under the cab when the doors close, and the harness plugs into the factory OBD-II connector with no wire splicing.

Why owners choose it

Auto-deploys the instant a door opens, then retracts flush under the rocker a few seconds after the doors close.
Plug-N-Play wiring: the vehicle-specific harness plugs into the factory OBD-II connector, so no factory wires are cut or spliced.
Extruded aluminum step board, 6 in. wide with a non-slip tread, rated to support 600 lb per side.
Die-cast aluminum linkage with PTFE coating and stainless steel pivot pins resist corrosion.
Weather-sealed electric motors and integrated LED step lights for all-weather, night-time use.
Hidden under the rocker when retracted for full ground clearance and a clean factory look.

What's included

Sold as a complete kit for both sides of the truck. Includes the driver- and passenger-side PowerStep assemblies with motors, a vehicle-specific Plug-N-Play wiring harness and control module that connect to the factory OBD-II connector with no splicing, mounting brackets and hardware, integrated LED step lights, and an installation guide. Crew Cab installs without modification; Quad Cab and Regular Cab boards require trimming.

Fitment

Fits 2019-2024 Ram 1500 (new DT body) in all cabs; Quad Cab and Regular Cab boards require trimming. Does not fit the 5-lug 1500 Classic/DS, which uses 76239-01A.

Which AMP step fits your truck

This 76240-01A is the new DT-body 1500 kit; the 2018-2023 Ram 1500 Classic (and the 2500/3500) uses 76239-01A, and the 2025-2026 Ram 1500 uses 76364-01A. Confirm your body (DT vs Classic) and year before ordering.

FAQ

Do I have to cut or splice any factory wires?

No. The PowerStep Plug-N-Play uses a vehicle-specific harness that plugs into the factory OBD-II connector, so no wire cutting or splicing is required.

Does the 76240-01A fit a Ram 1500 Classic?

No. This fits the new DT-body 2019-2024 Ram 1500 only. The 5-lug 1500 Classic uses PowerStep 76239-01A.

Do the boards need trimming?

Quad Cab and Regular Cab boards require trimming; Crew Cab installs without modification.

What warranty does AMP Research provide?

AMP backs the PowerStep with a 5-year/60,000-mile limited warranty against defects in materials and workmanship.

Vehicle Fitment

Years	Make	Model	Submodel
2019–2024	Ram	1500	All Cabs

Specifications

material: Extruded aluminum step with textured black powdercoat finish
type: Electric retractable running boards, Plug-N-Play (sold as a pair)
motors: Two (one per side), weather-sealed
wiring: Vehicle-specific plug-in harness to the factory OBD-II connector — no splicing
linkage: Die-cast aluminum, anodized and PTFE-coated, with stainless steel pivot pins
lighting: Integrated LED step lights
warranty: 5-year/60,000-mile limited manufacturer warranty
step width: 6 in. with non-slip tread
load rating: 600 lb per side
