- READY FOR WATER: Equipped with a weather-resistant, UV-stable face and controls that will stand up to sun, salt and moisture. Waterproof Rating of IPX6. Withstands jets of water from any direction thanks to IPX6 waterproof compliance.
- IPHONE COMPATIBLE: If you're an iPhone user, JVC makes it easy to make the most of your stored music. You'll be able to listen to saved music, music apps, and other audio content on select Apple devices with wired connection via USB
- REAR VIEW CAM INPUT: Backup cams are just about the most handy thing on earth, even in a boat or UTV. JVC equips the KD-MR1BTS with a rear-view camera input so you can add a view of what's behind you.
- CONFORMAL COATING: Is a protective chemical coating to safeguard electronic circuits from harsh environments that may contain moisture or chemical contaminants. It provides a barrier to contaminants such as salt-spray, thus preventing corrosion.
Specs
-
KD-MR1BTS
Monitor
- LCD Type
- 2.7" Color TFT
- Screen Brightness
- Yes (2 Levels)
Display
- Key Color
- Blue
Media Playback
- MP3 Compatible with Tag
- USB
- WMA Compatible with Tag
- USB
- FLAC Compatible with Tag
- USB (Up to 16bit, 48kHz)
Bluetooth Control
- Built-in Bluetooth[1]
- Yes (Ver 3.0)
- Audio Streaming & Control (A2DP, AVRCP)
- Yes
Android Control
- Android Music Playback
- Yes (via Bluetooth(R))
- Pandora Control (Available in countries that support this service.)
- Yes (via Bluetooth(R))
iPod/iPhone Control
- iPod/iPhone Music Playback
- Yes (via USB or Bluetooth(R))
- Pandora Control (Available in countries that support this service.)
- Yes (via USB or Bluetooth(R))
USB
- Position
- Rear
- USB Power Supply
- Yes (1.0A)
Inputs and Outputs
- AUX Input
- Rear (RCA L, R)
- Line Output Terminals (Pair)
- 2 Pairs (Front + Rear/Subwoofer Selectable)
- Pre-Output Level
- 2.0V
- Subwoofer Output with Level/Frequency Control
- Yes (Level 0 - 20)
- Subwoofer Output Level
- 4.0V
Tuner
- SiriusXM Ready
- Yes
- Radio Data Broadcast System (RBDS)
- Yes
- Preset Stations
- 18FM + 12AM + 6WB
- Weather Band Selection
- Yes
- FM
- Frequency Range (Frequency Step)
- 87.9 - 107.9MHz
- AM
- Frequency Range (Frequency Step)
- 530 - 1700kHz
- WB
- Frequency Range
- 162.40 - 162.55 (US & Canada)
Audio
- Maximum Power Output
- 50W x 4
- EQ
- Yes (7-Band Graphic EQ)
- Preset EQ
- Yes (8-Preset)
General
- Rear View Camera Input
- Yes
- Waterproof
- Yes (IPX6)
- Wired Remote Control
- Ready (RM-RK62M required)
- Antirust-coating for Marine
- Yes
- Dimensions (W x H x D)
- Installation Size
- Front Panel:4-9/16 x 4-3/16 x 1-9/16(115 x 106 x 39mm) , Body:Dia. 3-1/16 x 2-15/16(Dia. 77 x 74mm)
- Weight
- 2.0 lbs. (0.9kg) includes Trim Bezel, Mounting Plate, Screws
- Unit weight in individual package
- 2.76 lbs. (1.25kg)
[1]Available functions depend on mobile phone.
