ICON Stage 8 CDCV Suspension System for 2010-2024 Toyota 4Runner/FJ

Name: ICON Stage 8 CDCV Suspension System for 2010-2024 Toyota 4Runner/FJ
Brand: ICON
SKU: K53068T
Price: 7144.81 USD
Availability: InStock

$7,144.81 USD

Sale Sold out

Shipping calculated at checkout.

SKU:K53068T

Available to order — typically ships in ~1–2 weeks

Calculated shipping — oversized item
Typically ships in ~1–2 weeks
30-day hassle-free returns
Price match — found it cheaper?
Secure checkout — SSL encrypted

Key Features

0-3.5 inches of adjustable front lift plus 2 inches of rear lift for an aggressive, level stance
CDCV front coilovers deliver 10 selectable compression-damping levels for tunable ride quality
Tubular Delta Joint upper control arms retain factory alignment and add caster for stability
Rear 2.5 Omega bypass shocks offer 28 settings of compression and rebound adjustment
Complete front-and-rear kit with tubular rear links and adjustable track bar
Fully bolt-on installation with no cutting or welding required
KDSS compatible for easy fitment on equipped 4Runner and FJ Cruiser models

The ICON K53068T Stage 8 Suspension System is a complete bolt-on front-and-rear kit for the 2010-2024 Toyota 4Runner and 2010-2014 FJ Cruiser, delivering 0-3.5 inches of adjustable front lift and 2 inches of rear lift with CDCV-adjustable 2.5 Series front coilovers, tubular steel Delta Joint upper control arms, and 2.5 Omega bypass rear shocks.

Key Benefits

0-3.5 inches of adjustable front lift and 2 inches of rear lift to clear larger, more aggressive wheel and tire combinations
CDCV-equipped front coilovers provide 10 selectable levels of compression damping for on-the-fly tuning
Tubular Delta Joint upper control arms restore factory alignment specs and add caster for confident high-speed stability
Rear 2.5 Omega bypass shocks add 28 settings of compression and rebound adjustment for fine-tuned control
Complete bolt-on system requires no cutting or welding

What's Included

Front extended-travel 2.5 inch CDCV remote-reservoir coilovers with ICON-engineered coil springs
Tubular Delta Joint upper control arms
Rear 2.5 Aluminum Series Omega bypass remote-reservoir shocks
ICON rear coil springs (2 inch lift)
Tubular upper and lower rear links with pinion angle adjustment
Adjustable rear track bar

Fitment

This complete suspension system is engineered for the following Toyota platforms. It is a standalone system and does not require additional aftermarket components to achieve its rated lift.

2010-2024 Toyota 4Runner (front and rear)
2010-2014 Toyota FJ Cruiser (front and rear)

FAQ

Does the ICON K53068T fit a Lexus GX460?

No. The K53068T Stage 8 system is built for the 2010-2024 Toyota 4Runner and 2010-2014 FJ Cruiser. The Lexus GX460 uses a dedicated ICON system, not this part number.

What is the difference between K53068T and K53068?

Both are Stage 8 systems for the same trucks. K53068T uses tubular steel Delta Joint upper control arms; K53068 uses billet aluminum Delta Joint upper control arms.

Are the ICON K53068T shocks adjustable?

Yes. The front coilovers use ICON CDC Valve (CDCV) technology with 10 levels of external compression-damping adjustment, and the 2.5 Omega bypass rear shocks add 28 settings of compression and rebound adjustment.

Vehicle Fitment

Years	Make	Model	Submodel	Position
2010–2024	Toyota	4Runner	—	Front
2010–2014	Toyota	FJ Cruiser	—	Front

Specifications

valve: CDCV
rear lift: 2 in
front lift: 0-3.5 in (adjustable)
rear shock: 2.5 Omega bypass remote-reservoir, 28-position adjustable
standalone: yes
front shock: 2.5 in extended-travel CDCV remote-reservoir coilover
rear shocks: 2.5 Omega bypass, 28-position adjustable
restrictions: KDSS compatible (front sway bar relocation brackets not used on KDSS vehicles; reservoir bracket trimming may be required on some years)
system stage: Stage 8
front valving: CDCV (CDC Valve, 10 compression levels)
kdss compatible: yes
upper control arms: Tubular Delta Joint
