ICON Stage 8 CDCV 0-3.5in Lift for 2010-2024 Toyota 4Runner FJ Cruiser

Name: ICON Stage 8 CDCV 0-3.5in Lift for 2010-2024 Toyota 4Runner FJ Cruiser
Brand: ICON
SKU: K53068
Price: 8274.17 USD
Availability: InStock

$8,274.17 USD

Sale Sold out

Shipping calculated at checkout.

SKU:K53068

Available to order — typically ships in ~1–2 weeks

Calculated shipping — oversized item
Typically ships in ~1–2 weeks
30-day hassle-free returns
Price match — found it cheaper?
Secure checkout — SSL encrypted

Key Features

Externally adjustable CDCV coilovers with 10 levels of compression damping for on-the-fly ride tuning
2.5in extended-travel front coilovers with remote reservoirs for cooler, fade-free off-road performance
Billet aluminum Delta Joint upper control arms restore alignment geometry and add durability
Omega Series bypass rear shocks deliver tunable, controlled rear damping
0-3.5in front and 2in rear lift clears larger wheel and tire packages with a level stance
Complete standalone system with rear springs, adjustable links, and track bar included
Fully bolt-on with no cutting or welding and full KDSS compatibility

The ICON K53068 Stage 8 Suspension System is a complete bolt-on front-and-rear kit for the 2010-2024 Toyota 4Runner and 2010-2014 FJ Cruiser, delivering 0-3.5 inches of adjustable front lift and 2 inches of rear lift with CDCV-adjustable 2.5 Series front coilovers, billet aluminum Delta Joint upper control arms, and 2.5 Omega bypass rear shocks.

Key Benefits

Externally adjustable CDCV (CDC Valve) coilovers provide 10 levels of compression damping so you can dial in ride quality on the fly
2.5in extended-travel front coilovers with remote reservoirs run cooler and resist fade on long, rough trails
Billet aluminum Delta Joint upper control arms restore proper alignment geometry and add strength and durability
Omega Series bypass rear shocks add tunable rear damping for a planted, controlled ride
Fully bolt-on installation with no cutting or welding, and full KDSS compatibility

What's Included

Pair of 2.5in CDCV front coilover shocks with remote reservoirs and ICON coil springs
Billet aluminum Delta Joint upper control arms (pair)
2.5in Aluminum Series Omega bypass remote-reservoir rear shocks
ICON rear coil springs
Billet aluminum adjustable rear upper and lower links
Adjustable rear track bar

Fitment

Verified for the following Toyota applications (this exact part number K53068). The Lexus GX uses a different ICON part number.

2010-2024 Toyota 4Runner (front and rear)
2010-2014 Toyota FJ Cruiser (front and rear)

FAQ

Does the ICON K53068 fit a Lexus GX460?

No. The K53068 Stage 8 system is built for the 2010-2024 Toyota 4Runner and 2010-2014 FJ Cruiser. The Lexus GX460 uses a dedicated ICON system, not this part number.

Does the ICON K53068 include upper control arms?

Yes. K53068 includes billet aluminum Delta Joint upper control arms. K53068T is the same Stage 8 system with tubular steel Delta Joint upper control arms instead.

Are the ICON K53068 shocks adjustable?

Yes. The front coilovers use ICON CDC Valve (CDCV) technology with 10 levels of external compression-damping adjustment, and the 2.5 Omega bypass rear shocks add 28 settings of compression and rebound adjustment.

Vehicle Fitment

Years	Make	Model	Submodel	Position
2010	Toyota	4Runner	—	Rear
2010–2011	Toyota	4Runner	—	Front
2011–2012	Toyota	4Runner	—	Rear
2012	Toyota	4Runner	—	Front
2013	Toyota	4Runner	—	Rear
2013–2014	Toyota	4Runner	—	Front
2014	Toyota	4Runner	—	Rear
2015	Toyota	4Runner	—	Front
2015	Toyota	4Runner	—	Rear
2016	Toyota	4Runner	—	Front
2016	Toyota	4Runner	—	Rear
2017	Toyota	4Runner	—	Front
2017–2018	Toyota	4Runner	—	Rear
2018	Toyota	4Runner	—	Front
2019	Toyota	4Runner	—	Rear
2019	Toyota	4Runner	—	Front
2020	Toyota	4Runner	—	Rear
2020	Toyota	4Runner	—	Front
2021	Toyota	4Runner	—	Rear
2021	Toyota	4Runner	—	Front
2022	Toyota	4Runner	—	Rear
2022	Toyota	4Runner	—	Front
2023	Toyota	4Runner	—	Rear
2023	Toyota	4Runner	—	Front
2024	Toyota	4Runner	—	Rear
2024	Toyota	4Runner	—	Front
2010	Toyota	FJ Cruiser	—	Front
2010–2011	Toyota	FJ Cruiser	—	Rear
2011	Toyota	FJ Cruiser	—	Front
2012	Toyota	FJ Cruiser	—	Rear
2012	Toyota	FJ Cruiser	—	Front
2013	Toyota	FJ Cruiser	—	Rear
2013–2014	Toyota	FJ Cruiser	—	Front
2014	Toyota	FJ Cruiser	—	Rear

Specifications

notes: KDSS compatible; bolt-on, no cutting or welding
valve: CDCV
install: bolt-on, no cutting or welding; controller not required (manual CDCV adjustment)
rear lift: 2 in
track bar: adjustable, included
front lift: 0-3.5in adjustable
rear links: billet aluminum adjustable upper and lower links
rear shock: 2.5in Omega Series bypass, remote reservoir
standalone: yes
front shock: 2.5in coilover, remote reservoir, CDCV adjustable (10 levels)
kdss compatible: yes
upper control arms: billet aluminum Delta Joint (included)
