ICON Stage 8 CDCV Suspension System for 03-09 4Runner FJ GX470

Take your 2003-2009 Toyota 4Runner, 2007-2009 FJ Cruiser, or 2003-2009 Lexus GX470 to the top of the ICON lineup with the K53058T Stage 8 suspension system. This is ICON's most complete bolt-on package, combining extended-travel front coilovers, a Delta Joint tubular upper control arm kit, and a fully rebuilt rear link suspension for 0-3.5 inches of adjustable lift and dramatically improved travel, control, and ride quality.

Key Benefits

• Adjustable 0-3.5 inches of front lift to clear up to 33x11.50 tires and level the stance
• 2.5 Series extended-travel front coilovers with CDCV manual compression adjusters dial in ride feel on the trail or highway
• Delta Joint tubular upper control arms restore correct geometry, add strength, and resist contamination far better than rubber or heim joints
• Complete rear link, track bar, and spring package corrects pinion angle and maximizes rear articulation
• Fully serviceable, rebuildable shocks for long service life

What's Included

• Pair of 2.5 Series extended-travel front coilovers (CDCV manual adjusters)
• Delta Joint tubular steel upper control arm kit
• 2.0 Aluminum Series rear shocks
• 2-inch lift rear coil springs
• Tubular upper and lower rear trailing arms
• Adjustable rear track bar
• Mounting hardware

Specifications

• Brand: ICON Vehicle Dynamics
• Part Number: K53058T
• Stage: 8 (top-tier system)
• Front shock: 2.5 Series extended-travel coilover, CDCV manual compression adjuster
• Rear shock: 2.0 Aluminum Series
• Upper control arm: Delta Joint tubular steel (included)
• Lift range: 0-3.5 inches front and rear
• Position: Front and rear
• Recommended tire: 33x11.50

Fitment

Direct bolt-on fitment for the following vehicles. A 700 lb/in expedition front coil is available for heavily equipped builds. Remote reservoir brackets may interfere with some aftermarket bumper mounts or washer bottles.

• 2003-2009 Toyota 4Runner
• 2007-2009 Toyota FJ Cruiser
• 2003-2009 Lexus GX470
